Luminator LED Low-Profile
Stretch Light Bars

Models 12.1227 / 12.1237 / 12.1247 / 12.1257
Custom Models

• You can depend on the proven performance and reliability of Luminator LED Low-Profile Stretch Light Bars. Aerodynamically-designed housings are packed with 3W LEDs that are arranged to provide complete 360° coverage.
• Four basic lengths (27″ 37″, 47″ and 57″) are suitable for a wide variety of vehicles. Additional lengths ranging (in 10″ increments) from 67″ to 97″ will accommodate large size vehicles.
• All models have 3W Luminator LEDs with Total Internal Reflection optics for intensely bright light. Diffusing lenses on two-thirds of the Luminator LEDs disperse light horizontally. The remaining third provide concentrated forward light.
• Individual modules of (3) 3W Luminator LEDS are available in standard warning colors: amber, blue, green, red and white. The modules can be grouped into custom arrangements according to your specifications.
• All basic models have Luminator LEDs and a built-in flasher with 15 selectable patterns.
• Model 12.1227.008 has a 15′ straight power cord with a fused cigarette lighter plug with POWER & MODE switches, and four 90 lb – pull magnets.
• All hardwire models have a 15′ power cable and include your choice of vehicle-specific mounting kit, mounting feet or headache rack brackets.
• Customize any length light bar with optional features (available for an extra charge).
• Optional alley and take-down lights improve operator and public safety.
• Optional Stop / Tail / Turn feature coordinates the light bar with vehicle functions.
• Optional LED Signal Stick controller provides additional arrow patterns for improved traffic control.
• The low-profile, UV-resistant, polycarbon dome is aerodynamically designed to improve fuel efficiency.
• A heavy-duty extruded aluminum base provides a rigid structure that won’t warp or bend. A clear anodized coating covers the aluminum to inhibit corrosion.
• Specify driver- or passenger-side cable exit.
• Low-Profile Stretch Bars are also available with SHO-OFF LEDs and with Standard LEDs.
• 12V standard; also available in 24V upon request.
• 5 year warranty
• Made in the U.S.A.
