Baja Designs OnX6 Racer Edition

$779.95$2,599.95

Clear
SKU: N/A Category: Brand:

Description

Wanting more power and distance?  Then the Baja Designs OnX6 Racer Edition Series is your answer.  Engineered for speeds of 110+ MPH, the Racer Edition Series will satisfy your wants and needs. Developed specifically for Team Enlightened racers, this light bar features a secretive mad scientist design that provides our racers with a competitive advantage. An industry first 30 Day Satisfaction Guarantee & Limited Lifetime Warranty is included for the ultimate in purchase protection.

The OnX6™ Racer Edition LED Light Bar is BRIGHTER. BOLDER. BETTER.

Baja Designs Features:
Satisfactions Guarantee – 30 Day Money Back
Guarantee
Limited Lifetime Warranty – Complete Purchase Protection
uService® – Replaceable Lenses And Optics
ClearView® – All The Light, Right Where You Need It.
MoistureBlock™ – Waterproof, Rain Proof, Submersible
CopperDrive® – Only LED Driven At 100%
5000K Daylight – Less Driver Fatigue, Natural Color

10″ Specifications:
Wattage/Amps: 63W / 5.25A
Dimensions: 10″ x 4.29″ 2.69″
Weight: 4.25 lbs
LED Life Expectancy: 49,930 Hours
Front Lens: Hard Coated Polycarbonate
Housing: Aircraft Grade Aluminum w/Mil-Spec Hard Anodize
Bezel: Billet Machined Aluminum
Hardware & Bracket Material: Stainless Steel
Exceeds MIL-STD810G (Mil-Spec Testing)
Built-In Overvoltage Protection
IP69K (Waterproof up to 9ft & Pressure Washable)
IK10 Compliant (Mechanical Impact Testing)

20″ Specifications:
Wattage/Amps: 126W / 10.5A
Dimensions: 20″ x 4.29″ x 2.69″
Weight: 7.85 lbs
LED Life Expectancy: 49,930 Hours
Front Lens: Hard Coated Polycarbonate
Housing: Aircraft Grade Aluminum w/Mil-Spec Hard Anodize
Bezel: Billet Machined Aluminum
Hardware & Bracket Material: Stainless Steel
Exceeds MIL-STD810G (Mil-Spec Testing)
Built-In Overvoltage Protection
IP69K (Waterproof up to 9ft & Pressure Washable)
IK10 Compliant (Mechanical Impact Testing)

30″ Specifications:
Wattage/Amps: 189W / 15.75A
Dimensions: 30″ x 4.29″ x 2.69″
Weight: 11.45 lbs
LED Life Expectancy: 49,930 Hours
Front Lens: Hard Coated Polycarbonate
Housing: Aircraft Grade Aluminum w/Mil-Spec Hard Anodize
Bezel: Billet Machined Aluminum
Hardware & Bracket Material: Stainless Steel
Exceeds MIL-STD810G (Mil-Spec Testing)
Built-In Overvoltage Protection
IP69K (Waterproof up to 9ft & Pressure Washable)
IK10 Compliant (Mechanical Impact Testing)

40″ Specifications:
Wattage/Amps: 252W / 21A
Dimensions: 40″ x 4.29″ x 2.69″
Weight: 15.05 lbs
LED Life Expectancy: 49,930 Hours
Front Lens: Hard Coated Polycarbonate
Housing: Aircraft Grade Aluminum w/Mil-Spec Hard Anodize
Bezel: Billet Machined Aluminum
Hardware & Bracket Material: Stainless Steel
Exceeds MIL-STD810G (Mil-Spec Testing)
Built-In Overvoltage Protection
IP69K (Waterproof up to 9ft & Pressure Washable)
IK10 Compliant (Mechanical Impact Testing)

50″ Specifications:
Wattage/Amps: 315W / 26.25A
Dimensions: 50″ x 4.29″ x 2.69″
Weight: 18.65 lbs
LED Life Expectancy: 49,930 Hours
Front Lens: Hard Coated Polycarbonate
Housing: Aircraft Grade Aluminum w/Mil-Spec Hard Anodize
Bezel: Billet Machined Aluminum
Hardware & Bracket Material: Stainless Steel
Exceeds MIL-STD810G (Mil-Spec Testing)
Built-In Overvoltage Protection
IP69K (Waterproof up to 9ft & Pressure Washable)
IK10 Compliant (Mechanical Impact Testing)

Includes:

  • Baja Designs OnX6 Racer Edition LED Light Bar
  • Mounting Brackets


Patterns:

Racer Edition Spot:  A 4° beam focus for illumination WAY down the trail or road.  The Racer Edition Spot is for speeds of 110+ MPH or if you need to see a mile+ away. This is the latest version for our Team Enlightened racers and is designed to be used in conjunction with additional Wide Driving and/or Driving/Combo beam lights. (Lighting Zone 5+)

Driving/Combo: Maximum trail coverage in a single light.  The Driving/Combo pattern is equipped with both Wide Driving (42°) and Spot (6°) optics to provide you with a smooth blend of light for both near field applications and distance (Lighting Zone 3)

Additional information

Weight N/A
Dimensions N/A
Beam Pattern

Driving-Combo, Racer Edition Spot

Size

10", 20", 30", 40", 50"
