Sale!

HELLA HID Work Light Module120 AS200

$699.95 $200.00

These lamps are on CLEARANCE – TWO REMAIN ONLY

Features:
• Fiber-glass reinforced plastic housing
• Integrated 3rd generation ballast
• 2.5 times the light intensity of a 55W Halogen bulb
• Heavy duty stainless steel bracket
• Integrated recessed handle
• Includes high performance harness with fuse & relay
• IP5K9K (dust protected and withstands high pressure wash)
• EMC Class 3 (per CISPR 25)
• Approximate capsule service life = 2,500 hours
• Meets Hella Norm N67001 – Class 4

Description

HELLA AS200 Xenon Work Lamp

HELLA HID Work Light – From your Canadian HELLA Dealer – Authority Lighting

These lamps are on CLEARANCE – TWO REMAIN ONLY

Features:
• Fiber-glass reinforced plastic housing
• Integrated 3rd generation ballast
• 2.5 times the light intensity of a 55W Halogen bulb
• Heavy duty stainless steel bracket
• Integrated recessed handle
• Includes high performance harness with fuse & relay
• IP5K9K (dust protected and withstands high pressure wash)
• EMC Class 3 (per CISPR 25)
• Approximate capsule service life = 2,500 hours
• Meets Hella Norm N67001 – Class 4

Specifications:
• Voltage: 12VDC
• Light Source: D2S 35W Capsule
• Ballast Unit: Gen 4
• Power Consumption: 42W
• Luminous Flux (calculated): 3200clm
• Luminous Flux (measured): 2600clm
• Luminous Efficacy (lumens per watt): 62lm/W
• Light Temperature: Approx. 4250° K
• Ambient Temperature: -40°C to +50°C
• Housing Material: HD Plastic
• Optics: Lens & Reflector
• Lens Material: Glass
• Connection: Integrated AMP
• Bracket: SS 4-point
• Harness: Included
• Vibration Dampening: No
• Packaging: Box
• Minimum Order Qty: 1

Technology:
• Xenon

Single Lamp includes:
• (1) Lamp
• Universal Mounting Hardware

Part Numbers:

AS200 Xenon – Close Range – 12V
996142021
AS200 Xenon – Close Range – 24V 996142031
AS200 Xenon – Long Range – 12V 996142061
AS200 Xenon – Long Range – 24V 996142071



Spare Parts and Accessories:

Pigtail 300mm with 2 Pin DT Connector H84985241
Pigtail 200mm with 2 Pin AMP Connector H84258021
High Performance D2S Xenon Capsule 12V/24V 35W H83075001
Lamp Insert AS200/300/400 D2S/D1S Close Range 990305021
Lamp Insert AS200/300/400 D2S/D1S Long Range 909305031
High Performance 12V Gen 3 Xenon Ballast Unit 007760451
High Performance 24V Gen 3 Xenon Ballast Unit 007810091



Additional information

Weight 2 lbs
Dimensions 12 × 12 × 12 in
